Anwendung: Sandstrahlen
Empfohlene Modelle:
LUY100-14,LUY120-12,LUY250-12,LUY270-10,LUY200-10,LUY220-8
Arbeitsdruck: 7-10bar (100-250psi)
Luftstrombereich: 10-27m3/min (350-953cfm)
max. Umgebungstemperatur: 50 °C (122 °F)
Modell | 050-7 | 100-10 | 120-12 | 150-13 | 140-14 | 200-10 | 230-14 | 250-12 | 270-10 |
Arbeitsdruck, bar | 7 | 10 | 12 | 13 | 14 | 10 | 14 | 12 | 10 |
Durchfluss (m3/min) | 5 | 10 | 12 | fünfzehn | 14 | 20 | 23 | 25 | 27 |
Lärm (in 7m Entfernung, dBA ) | 70 ±3 | 81 ±3 | 83 ±3 | 83 ±3 | 83 ±3 | 83 ±3 | 79 ±3 | 79 ±3 | 79 ±3 |
Fassungsvermögen des Kraftstofftanks, l | 67 | 120 | 120 | 180 | 180 | 250 | 470 | 470 | 470 |
Kompressorölkapazität, l | 8 | 26 | 26 | 28 | 23 | 55 | 65 | 65 | 65 |
Marke des Motors | Kubota | YuChai | YuChai | YuChai | YuChai | YuChai | CUMMINS | CUMMINS | CUMMINS |
Motormodell | V1505 T | YC4A130-H311 | YC4A160-H300 | YC6J190-T304 | YC6J175-H301 | YC6A240-H301 | QSL8.9-325-30 | QSL8.9-325-30 | QSL8.9-325-30 |
Motorleistung, Kw | 33 | 96 | 118 | 140 | 129 | 176 | 242 | 242 | 242 |
Normale Motordrehzahl, U/min | 2950 | 2300 | 2200 | 2550 | 2300 | 1950 | 2000 | 2000 | 2000 |
Entladen Motordrehzahl, U / min | 1950 | 1400 | 1400 | 1400 | 1200 | 1200 | 1300 | 1300 | 1300 |
Motor-Inspiration | Turbolader | Turbolader | Turbolader | Turbolader | Turbolader | Turbolader | Turbolader | Turbolader | Turbolader |
Abmessung, mm | 2960 x 1350 x 1420 | 3700 x 1790 x 1900 | 2400 x 1800 x 2120 | 3000 x 2000 x 2190 | 4322 x 1950 x 2010 | 4322 x 1950 x 2270 | 5260 x 1800 x 2630 | 5260 x 1800 x 2630 | 5260 x 1800 x 2630 |
Gewicht (kg | 750 | 1650 | 1560 | 1990 | 2250 | 2685 | 4835 | 4835 | 4835 |
